Classic Plus EA14+EH1T (60Hz)

Specification	EA1418 + EH112417	EA1424 + EH112417	EA1430 + EH113817	EA1436 + EH113817	EA1442 + EH114821	EA1446 + EH114821	EA1460 + EH1176024
Rated Cooling Capacity (AHRI)	18,000 Btu/hr	24,000 Btu/hr	29,400 Btu/hr	35,600 Btu/hr	41,000 Btu/hr	46,500 Btu/hr	58,000 Btu/hr
Rated Cooling Capacity (T3)	16,200 Btu/hr	20,200 Btu/hr	24,700 Btu/hr	29,150 Btu/hr	34,700 Btu/hr	40,900 Btu/hr	47,500 Btu/hr
EER (AHRI)	13.0 Btu/Wh	13.0 Btu/Wh	13.0 Btu/Wh	12.5 Btu/Wh	12.0 Btu/Wh	12.5 Btu/Wh	12.0 Btu/Wh
EER (T3)	9.3 Btu/Wh	8.4 Btu/Wh	8.5 Btu/Wh	8.6 Btu/Wh	8.5 Btu/Wh	8.5 Btu/Wh	8.3 Btu/Wh
Rated Air Flow	600 CFM	800 CFM	1,000 CFM	1,200 CFM	1,400 CFM	1,400 CFM	1,600 CFM
ODU Dimensions (L×W×H)	755×755×635 mm	755×755×635 mm	755×755×685 mm	857×857×685 mm	859×859×787 mm	908×908×787 mm	908×908×889 mm
ODU Weight	55.3 kg	63.9 kg	68.5 kg	77.6 kg	90.7 kg	100.3 kg	108.8 kg
IDU Dimensions (L×W×H)	1,080×551×445 mm	1,080×551×445 mm	1,080×551×445 mm	1,080×551×445 mm	1,282×551×533 mm	1,282×551×533 mm	1,410×551×622 mm
IDU Weight	48 kg	48 kg	50 kg	50 kg	65 kg	65 kg	80 kg
Refrigerant	R410A	R410A	R410A	R410A	R410A	R410A	R410A
